Features

• WRAS (UK) GOST-R (Russia) Expert Conclusion (Russia) EAC Conforming (Russia) UkrSepro (Ukraine) RoHS Compliant. Freezing of the fluid in the installation may severely damage the valve. Approvals apply to specific configurations only. S.64 Brass Ball Valve - 1/4 Turn, ISO 5211 Actuator Mounting Pad. More and more automation is required at all levels in our society and the S.64 range is the answer to all our needs for reliable actuated ball valves. It features a special seat design to automatically compensate for wear and it has successfully passed 100.000* cycle life tests. ISO 5211 actuator mounting pad allow direct mounting of electric and pneumatic actuators, with no bracket or coupling required Application : Air, Water, Industry Operating Temperature : -20ﾟC (-4ﾟF) / +150ﾟC (+302ﾟF) Operating pressure : PN20 (300 PSI), non-shock cold working pressure Threads : EN 10226-1, ISO 228 parallel female by female threads Port : Full Connections options : FxF Stem Configuration : Blowout-proof nickel plated brass stem, with two FPM O-rings at the stem for maximum safety Ball seats : Pure PTFE self-lubricating, with flexible-lip design Body : Full port to DIN 3357 for maximum flow 100% Made in Italy Chrome plated brass ball for longer life Silicone-free lubricant on all seals 24h 100% seal test guaranteed Dual sealing system allows valve to be operated in either direction making installation easier No metal-to-metal moving parts No maintenance ever required Quality : Hot forged sand blasted, nickel plated brass body and cap sealed with Loctite or equivalent thread sealant; Finest brass according to EN 12165 and EN 12164 (formerly DIN 17660 and UNI 5705-65) specifications. EN 10226-1, ISO 228 parallel female by female threads. Thread:. Blowout-proof nickel plated brass stem Two FPM O-rings at the stem for maximum safety. Stem:. Reinforced PTFE self-lubricating seats with flexible-lip and wear compensation design. Seals:. 40 Bar (600 PSI) up to 2in., 30 Bar (450 PSI) over 2in. Non-shock cold working pressure For *** with dangerous fluids temperature rating is -20ﾟC +60ﾟC and pressure rating is 5 bar. Working Pressure:. -20ﾟC (-4ﾟF) +170ﾟC (+350ﾟF). Operating Temperature:
