Features

• DMS-20PC-1-LM - Self-Powered LED AC Voltage Monitor. The digital panel voltmeter DMS-20PC-1-LM is a component-size, self-contained, low-cost ac voltmeter for true line measurements. It requires no additional components or auxiliary power. Simply plug it into any wall outlet and instantly read voltages from 85 to 264 Vac. DMS-20PC-1-LM employs half-wave sinusoidal averaging (RMS calibrated) and has a display resolution of 1 Vac over its full input range. Packaged in a red-filter case with built-in bezel, the meter is fully encapsulated for ruggedness. The unit is overvoltage protected to 300 Vac. This low-cost meter is ideal for industrial, laboratory, office and field-service applications. Its miniature size is perfect for design into high-*** consumer electronics, laboratory instrumentation and other products requiring accurate ac line monitoring. Digital AC voltmeters with a large 9.4 mm blue LED display Input voltage ranges is 85-264 Vrms Half-wave averaging, RMS calibrated Self-powered, only two connections required Subminiature size with 35x22.4x25.4 mm Plugs directly into USA-style wall outlets Screw terminals for panel mounting Fully encapsulated for harsh environments
