Electronic/Electrical Parts and Controll Equipments
63-8006-27 ON Semi 2N5551BU NPN Transistor, 600 mA, 160 V, 3-Pin TO-92 2N5551BU
model:
63-8006-27
brand:
ON Semiconductor
Product Description
Product Model: 63-8006-27Product Brand: ON Semiconducto […]
Contact Us
Product Details
Product Model: 63-8006-27
Product Brand: ON Semiconductor
Features
- Small Signal NPN Transistors, Over 100V, Fairchild Semiconductor
Spec
- Quantity:1bag(200pieces)
- Transistor Type:NPN
- Maximum DC Collector Current:600 mA
- Maximum Collector Emitter Voltage:160 V
- Package Type:TO-92
- Mounting Type:Through Hole
- Maximum Power Dissipation:625 mW
- Minimum DC Current Gain:80
- Transistor Configuration:Single
- Maximum Collector Base Voltage:180 V
- Maximum Emitter Base Voltage:6 V
- Maximum Operating Frequency:100 MHz
- Pin Count:3
- Number of Elements per Chip:1
- Maximum Collector Emitter Saturation Voltage:0.20 V
- CODE No.:805-1100
