63-8004-53 160kΩ 0805 Thick Film SMD Resistor ±1% 0.125W 804-6613
Product Description
Product Model: 63-8004-53Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-8004-53
Product Brand: RS PRO
Features
- 0805 Format Resistor, RS Series - ( 25kΩ → 224.9kΩ ). Thick film chip resistor with a highly reliable multilayer electrode construction and compatible with all soldering process. Resistor Applications include:-. Telecommunication Equipments Radio and Tape Recorders, TV Tuners Video Cameras, Watches, Pocket Calculators Automotive Industry Computers, Instruments
Spec
- Quantity:1set(5000pieces)
- Resistance:160kΩ
- Technology:Thick Film
- Package/Case:0805 (2012M)
- Tolerance:±1%
- Power Rating:0.125W
- Temperature Coefficient:±100ppm/°C
- Minimum Operating Temperature:-55°C
- Maximum Operating Temperature:+155°C
- CODE No.:804-6613
