63-8003-53 ON Semiconductor GBPC2506, Bridge Rectifier, 25A 600V, 4-Pin GBPC GBPC2506
model:
63-8003-53
brand:
ON Semiconductor
Product Description
Product Model: 63-8003-53Product Brand: ON Semiconducto […]
Contact Us
Product Details
Product Model: 63-8003-53
Product Brand: ON Semiconductor
Features
- UL #E258596. Bridge Rectifiers with Push-on Terminals, GBPC 25 Series, Fairchild Semiconductor. High Current 25A Glass Passivated die construction Integrally molded heat-sink provided very low thermal resistance for maximum heat dissipation Isolated voltage from case to lead over 2500V Fast-on Terminals
Spec
- Quantity:1box(50pieces)
- Bridge Type:Single Phase
- Peak Average Forward Current:25A
- Peak Reverse Repetitive Voltage:600V
- Mounting Type:Screw Mount
- Package Type:GBPC
- Pin Count:4
- Diode Technology:Silicon Junction
- Configuration:Single
- Peak Non-Repetitive Forward Surge Current:300A
- Maximum Operating Temperature:+150 °C
- Minimum Operating Temperature:-55 °C
- Peak Forward Voltage:1.1V
- Peak Reverse Current:500µA
- Length:29mm
- Dimensions:29 x 29 x 11.23mm
- CODE No.:145-5573
