63-8000-38 RS PRO SPST Non-Latching Relay PCB Mount, 24V dc Coil, 6A 800-4552
Product Description
Product Model: 63-8000-38Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-8000-38
Product Brand: RS PRO
Features
- UL (File no. E133481), VDE (File no. 40020043). Slim Relays. Slim size (width 5mm) High sensitivity, coil power 170mW 4kV dielectric strength (between coil and contacts) Surge voltage up to 6kV (between coil and contacts) Wash tight Clearance/creepage distance 8mm
Spec
- Quantity:1piece
- Coil Voltage:24V dc
- Coil Power:170mW
- Coil Resistance:3.39 kΩ
- Isolation Coil To Contact:4kV ac
- Contact Configuration:SPST
- Mounting Type:PCB Mount
- Switching Current:6A
- Terminal Type:Through Hole
- Number of Poles:1
- Maximum Switching Voltage AC:400V ac
- Maximum Switching Voltage DC:125V dc
- Standards Met:RoHS Compliant, UL E133481, VDE 40020043
- CODE No.:800-4552
