Electronic/Electrical Parts and Controll Equipments
63-7999-94 Finder22 Series 4NO Non-Latching Relay DIN Rail, 24 V dc, 24 V ac Coil, 40A 22.44.0.024.4310
Product Description
Product Model: 63-7999-94Product Brand: Finder Features […]
Contact Us
Product Details
Product Model: 63-7999-94
Product Brand: Finder
Features
- 22.44 & 22.64 Series - Modular contactors. Finder 22 series 4-pole modular contactors, rail mounted, with 4 pole. 40 - 63 A Continuously duty for the coil and contacts AC/DC silent coil with varistor protection Protective separation (reinforced insulation) between coil and contacts Compliant with EN 61095:2009 and with EN 60947-4-1:2009 35 mm rail mount Screw terminal Auxiliary modules available for 22.44 and 22.64 series (800-2916 and 800-2925)
Spec
- Quantity:1piece
- Coil Voltage:24 V dc, 24 V ac
- Coil Power:5W
- Isolation Coil To Contact:6kV
- Contact Configuration:4NO
- Mounting Type:DIN Rail
- Switching Current:40A
- Terminal Type:Screw
- Number of Poles:4
- Maximum Switching Voltage AC:440V ac
- Length:53.5mm
- CODE No.:800-2843
