63-7998-96 DiodesZetex 74HC00S14-13, Quad 2-Input NAND Schmitt Trigger Logic Gate, 14-Pin SOIC 74HC00S14-13
Product Description
Product Model: 63-7998-96Product Brand: DiodesZetex Fea […]
Contact Us
Product Details
Product Model: 63-7998-96
Product Brand: DiodesZetex
Features
- 74HC Family, DiodesZetex. The 74HC family by DiodesZetex is made up of high-speed logic devices that *** CMOS circuitry. It is a series of general purpose logics ICs with low power consumption. A variety of types are available including standard logic gates, hex inverters, buffers, decoders ; demultiplexers, Schmitt trigger inverters, counters ; shift registers.. Supply Voltage Range: 2 V to 6 V Sinks or Sources 4 mA at VCC: 4.5 V CMOS Low Power Consumption ESD Protection Exceeds JESD 22 - 200V Machine Model (A115-A)- 2000V Human Body Model (A114-A) - Exceeds 1000V Charged Device Model (C101C)
Spec
- Quantity:1set(2500pieces)
- Logic Function:NAND
- Mounting Type:Surface Mount
- Number of Elements:4
- Number of Inputs per Gate:2
- Schmitt Trigger Input:Yes
- Package Type:SOIC
- Pin Count:14
- Logic Family:HC
- Input Type:Schmitt Trigger
- Maximum Operating Supply Voltage:6 V
- Maximum High Level Output Current:-4mA
- Maximum Propagation Delay Time @ Maximum CL:135 ns @ 50 pF
- Minimum Operating Supply Voltage:2 V
- Maximum Low Level Output Current:5.2mA
- Minimum Operating Temperature:-40 °C
- CODE No.:169-7230
