63-7997-98 Single Pole Single Throw (SPST) Momentary P***ant Switch, 400 mA @ 32 V ac ISR3SAD600107
Product Description
Product Model: 63-7997-98Product Brand: APEM Features P […]
Contact Us
Product Details
Product Model: 63-7997-98
Product Brand: APEM
Features
- P***ant Switch (IP67). IP 67 p***ant switch supplied with coiled cord and 3.5mm jack plug. Simple, attractive, reliable design (Min. electrical life 500,000 cycles) Lead length 0.5m relaxed, 2m under light tension Suitable for *** in numerous applications including, push to talk applications, emergency (eg nurse call), light control, activation (eg snap-shot), home automation etc Max. current/voltage rating with resistive load: 400mA @ 32Vac, 100mA @ 50Vdc Normally open contacts For p***ant control stations see typically, stock no ; 251-2561 251-2561
Spec
- Quantity:1piece
- Contact Configuration:Single Pole Single Throw (SPST)
- Switch Operation:Momentary
- Lead Length:0.5m
- IP Rating:IP67
- Contact Current Rating:400 mA @ 32 V ac
- Terminal Type:3.5mm Stereo Plug
- Contact Resistance:50mΩ
- Minimum Operating Temperature:-40°C
- Maximum Operating Temperature:+85°C
- Contact Material:Gold Plated Silver
- Operating Temperature Range:-40 → +85°C
- CODE No.:797-6670
