63-7996-58 RS PRO Gauge for Air, Gas, Hydraulic Fluid, Liquid, Water Pressure Sensor, 1bar Max Pressure Reading , 9 → 32 V 797-4983
Product Description
Product Model: 63-7996-58Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-7996-58
Product Brand: RS PRO
Features
- RS Pressure Transducers - IND series. The IND series is suitable for a wide range of industrial applications. It has a probe which ***s a piezo-resistive ceramic sensor, giving excellent media compatibility within a stainless steel housing. Piezo-resistive thick film ceramic sensor Stainless steel body +/- 0.25% accuracy Different outputs including mV, Volts and mA Microprocessor based amplifier Operating temperature: -20 ºC to +135 ºC Temperature compensated, calibrated and supplied with a traceable serial number and calibration certificate
Spec
- Quantity:1piece
- Pressure Reading Type:Gauge
- Minimum Pressure Reading:0bar
- Maximum Pressure Reading:1bar
- Accuracy:±0.25 %
- Output Type:Current
- Media Measured:Air, Gas, Hydraulic Fluid, Liquid, Water
- Process Connection:BSP 1/4
- Analogue Output:4 → 20 mA
- Maximum Current:20 mA
- Supply Voltage:9 → 32 V dc
- Housing Material:Stainless Steel
- IP Rating:IP65
- Maximum Operating Temperature:+135°C
- CODE No.:797-4983
