Features

• 9116B Type - Ex Universal Converter. The 9116B is an universal converter with 1-channel. The device is for converting and scaling of temperature, voltage, potentiometer and linear resistance signals. 1-channel universal converter Input for RTD, TC, Ohm, potentiometer, mA and V Reduced Uo Ex data ; 8.3 V for active input signals Active / passive mA output and relay output Configuration and monitoring by way of detachable display front (PR 4501); process calibration and signal simulation Copying of the configuration from one device to others of the same type via the display front Please order the Display Front PR4501 separately (stock-no. ; 796-6890 796-6890 ) Advanced relay configuration, e.g. setpoint, window, delay, sensor error indication and power monitoring Power supply and signal isolator for 2-wire transmitters Can be mounted in the safe area and in zone 2 / cl. 1 div. 2 and receive signals from zone 0, 1, 2 and zone 20, 21, 22 including M1 / Class I/II/III, Div. 1, Gr. A-G SIL 2-certified via Full Assessment. Designed, developed and certified for *** in SIL 2 applications according to the requirements of IEC 61508 Front LED indicates operation status, malfunction and relay status 2.6 kVac galvanic isolation between input, output and supply Can be supplied separately or installed on power rail, PR type 9400 DIN rail mounting
