Spec

• Content: With nuts
• Material: Body/Contact: Brass, Spring/E-Ring: Stainless steel
• Treatment: Body contact: Nickel base gold-plated
• Current rating: 5A
• Contact resistance: 10 m.OMEGA. or less
• Endurance: 10,000 times or more
• Mountable plate thickness: 10. to 3.0 mm
• Mounting hole diameter: 4.2 phi
• Working power: 200 g with 1 mm stroke
• Stroke: 1.5 mm
• Operating temperature range: -20 degrees C to + 100 degrees C
• Entries: 10
• Use for charging and discharging batteries, etc. Can be fixed with inrush current compatible nut.
• RoHS compliant
• Quantity: 1 bag (10 bottles)
