Electronic/Electrical Parts and Controll Equipments
63-7970-35 TRACOPOWER TMR 1 1W Isolated DC-DC Converter Through Hole, Voltage in 18 → 36 V dc, Voltage out 24V dc TMR 1-2415
Product Description
Product Model: 63-7970-35Product Brand: TRACOPOWER Feat […]
Contact Us
Product Details
Product Model: 63-7970-35
Product Brand: TRACOPOWER
Features
- Traco 1W SIP Fully Regulated Isolated DC-DC Converter - TMR 1 Series. The Tracopower TMR 1 series is a compact 1W isolated DC-DC converter in SIP package. The TMR 1 has a wide 2:1 input voltage range and fully regulated outputs. Wide 2:1 input voltage range Fully regulated outputs Operating temperature -40°C to +85°C No minimum load required I/0 isolation 1500 VDC Short circuit protection
Spec
- Quantity:1piece
- Output Voltage:24V dc
- Input Voltage Range:18 → 36 V dc
- Input Voltage Nominal:24 V dc
- Isolation Voltage:1500V dc
- Power Rating:1W
- Output Current:42mA
- Mounting Type:Through Hole
- Number of Outputs:1
- Efficiency:78%
- Package:SIP
- Load Regulation:1%
- Maximum Temperature:+85°C
- Series:TMR 1
- CODE No.:781-3229
