Features

• Altecnic Series 313 Safety Relief Valve. The Altecnic series 313 safety relief valves with presure gauge are ***d in domestic hot water systems to protect the hot water cylinder and in heating systems to protect boiler and other components. The valve is selected for the required set pressure. As the pressure rises, when the discharge pressure is reached the valve opens and discharges to atmosphere, preventing the pressure within the system reaching levels which would be dangerous for the boiler, hot water storage cylinder and any personnel in the adjacent vicinity. Temperature range: 5 to 110°C Medium: water and air Set pressure range: 2.5 to 8 bar Max. static pressure: 10 bar PED category: IV WRAS approved product Body Brass: BS EN 12165 CW617N Cover Brass: BS EN 12165 CW617N Stem Brass: BS EN 12164 CW614N Diaphragm: EPDM Spring: Stainless steel Control Knob: ABS Polymer
