Features

• CM-ESS Voltage Monitoring Relay - Single Phase AC/DC. Dep***ing on the configuration, the voltage monitoring relays CM-ESS.1 and CM-ESS.2 can be ***d for over- or undervoltage monitoring in single-phase AC and/or DC systems. The voltage to be monitored (measured value) is applied to terminals B-C. The devices work according the open-circuit principle. If the measured value exceeds resp. drops below the adjusted threshold value, the output relay(s) energize(s): on the CM-ESS.1 immediately, on the CM-ESS.2 after the set tripping delay TV. If the measured value exceeds resp. drops below the threshold value plus resp. minus the adjusted hysteresis, the output relay(s) de-energize(s). Monitoring of DC- and AC-voltages from 3-600V RMS measuring principle One device includes 4 measuring ranges: 3-30V, 6-60V, 30-300V, 60-600V Over- and undervoltage monitoring configurable Hysteresis adjustable from 3-30% Tripping delay TV adjustable 0; 0.1-30s 3 supply voltage versions 2 c/o contacts 22.5mm width 3 LED's for status indication
