Features

• Transmission performance: Category 6 / Class EA up to 500 MHz acc. to ISO/IEC 11 801:2002,EN 50 173-1 Connector standard acc. to IEC 60 603-7. Cable not included. Harting RJ Industrial® 10G RJ45 Cat6 8 Pole Connector Set. From Harting, the RJ Industrial® series of Cat6 10G RJ45 8 pole ethernet-data connectors have a compact design which can be field assembled using HARAX® for quick tool-less IDC termination. These RJ Industrial® Cat6 plug connectors have a mating face to RJ45 IEC 60 603-74, a data transmission rate of 1/10 gb Ethernet and are fully shielded with 360° contact. The housings of these RJ45 10G connector plug sets are made from black UL 94-V0 polyamide. They can also be connected to cables which have a cross section of AWG 27 to AWG 22 (solid or stranded) and a 1.6mm maximum conductor diameter. All models are highly reliable and excellent quality. The RJ Industrial® Series of connectors includes the following:. Stock number ; 714-8544 714-8544 is a straight RJ45 8 pole connector which accepts a cable diameter of 4.5 mm to 9 mm. Stock number ; 765-9081 765-9081 is a 45° angled RJ45 8 pole connector with 4 cable outlet options which accept a cable diameter of 4.5 mm to 8 mm.
