63-7818-20 Nichicon 10μF 35V dc Aluminium Polymer Capacitor, Surface Mount 6.3 (Dia.) x 5.9mm +125°C 6.3mm 2.1mm PCX1V100MCL1GS
Product Description
Product Model: 63-7818-20Product Brand: NICHICON Featur […]
Contact Us
Product Details
Product Model: 63-7818-20
Product Brand: NICHICON
Features
- CX Series. Nichicon CX Series Aluminium Electrolytic Capacitors are high reliability polymer capacitors which are rated up to 2000 hours. The CX series capacitors offer a high temperature range, high voltage, low ESR, and high ripple current. The CX series design makes them suitable for applications including motherboards and automobile infotainment systems. High reliability Low ESR High ripple current Long life up to 3000 hours Lead free reflow soldering
Spec
- Quantity:1set(1000pieces)
- Capacitance : 10µF
- Voltage : 35V dc
- Mounting Type : Surface Mount
- Technology : Polymer
- Dimensions : 6.3 (Dia.) x 5.9mm
- Height : 5.9mm
- Minimum Operating Temperature : -55°C
- Diameter : 6.3mm
- Maximum Operating Temperature : +125°C
- Lifetime : 3000h
- Series : CX
- Leakage Current : 70 μA
- CODE No.:173-3288
