63-7811-66 RS PRO Ball Brass Ball Valve with Electric Actuator, 1/2 in BSP 760-5700
Product Description
Product Model: 63-7811-66Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-7811-66
Product Brand: RS PRO
Features
- Stainless Steel Ball Valve with Electric Actuator. Body - CF8M - 316 S/S Ball - 316 S/S Stem Seal - PTFE Ball Seal - PTFE 1,000 PSI Rated Enclosure Rated Weather proof IP67 Motor: 24Vdc Multi voltage 24Vdc, 95-240Vac Limit Switches 2 x open/close SPDT, 250Vac 6A rating Auxiliary Limit Switches 2 x open/close SPDT, 250Vac 6A rating Indicator LED lamp Indicator (Open/Close) Manual Override Push Button with Manual lever Conduit Entries 1 x PG11 with 3m flying lead. 11 wires External Coating Polyester Powder Coating Base and Bore ISO5211(F03/04/05) and 11mm Double Square
Spec
- Quantity:1piece
- Valve Type : Ball
- Default Valve Position : NC
- Return Type : Spring
- Connection : 1/2 in BSP
- Maximum Working Pressure : 1000 psi
- Thread Size : 1/2in
- Thread Standard : BSP
- CODE No.:760-5700
