63-7810-32 Finder OFF Delay with Control Signal Single Timer Relay, 0.05-10 s, 0.05-10 h, 0.05-10 min, 0.05-10 d, SPDT, 1 83.41.0.240.0000
Product Description
Product Model: 63-7810-32Product Brand: Finder Features […]
Contact Us
Product Details
Product Model: 63-7810-32
Product Brand: Finder
Features
- 83 Series - Off Delay Timer. Single Pole 22.5 mm wide Eight time scales from 0.05s → 10 days High input/output isolation Wide supply range 24 → 240 Vac/dc 35 mm DIN rail (EN 60715) mount Blade + cross - both flat blade and cross head screw drivers can be ***d to adjust the range and function selectors, the timing trimmer, and to disengage the rail mounting clip Multi-voltage versions with PWM clever technology
Spec
- Quantity:1piece
- Supply Voltage : 24 → 240 V ac/dc
- Time Range : 0.05-10 s, 0.05-10 h, 0.05-10 min, 0.05-10 d
- Mode of Operation : OFF Delay with Control Signal
- Mounting Type : DIN Rail
- Number of Timer Functions : Single
- Number of Contacts : 1
- Series : 83 Series
- Time Increment : Days, Hours, Minutes, Seconds
- Power Supply : External
- Contact Configuration : SPDT
- Current Maximum : 0.12 A
- Minimum Voltage : 16.8 V ac/dc
- Maximum Voltage : 265 V ac / V dc
- Width : 22.5mm
- CODE No.:759-6659
