63-7805-94 Banshee Excel Lite Sounder Beacon, 110dB, Red Xenon, 9 → 30 V dc 90015R0
Electronic/Electrical Parts and Controll Equipments

63-7805-94 Banshee Excel Lite Sounder Beacon, 110dB, Red Xenon, 9 → 30 V dc 90015R0

model: 63-7805-94
brand: Hosiden Besson

Product Description

Product Model: 63-7805-94Product Brand: Hosiden Besson […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-7805-94
Product Brand: Hosiden Besson

Features

  • EN54-3 by LPCB. To maintain IP rating when using a deep base, *** wall mounting bracket supplied. Do not drill fixing holes in deep base. Use suitably rated 20mm cable glands to fit cables or conduit via side knock-outs. Fit ‘O ‘ Ring seal between lens and base. Banshee Excel Lite Xenon Sounder / Beacon. The Banshee Excel Lite Sounder / Beacon from Hosiden Besson has 32 ***r selectable tones with a choice of 3 volume levels and ***s the very latest strobe technology. Manufactured from a flame retardant polymer these sounder and beacon units are available with either a shallow or deep base and with the choice of a clear, amber or red coloured lens. The Banshee Excel Lite will meet the majority of Fire and Security applications and has the option of indep***ent or combined operation. Features and Benefits. EN54 - 3 approved by LPCB Ultra low current consumption 32 ***r selectable tones Choice of 3 volume levels Rated IP66 for deep base and IP45 for shallow base units Installation via side ; rear cable entry Easy push ; twist lockable bayonet mounting Temperature range from -20 to +70°C Simple in ; out wiring blocks

Spec

  • Quantity:1piece
  • Supply Voltage : 9 → 30 V dc
  • Lens Colour : Red
  • Mounting Style : Bayonet Mount
  • Current Type : DC
  • Light Effect : Strobe
  • Sounder Type : Electronic
  • Decibels at 1 Metre : 110dB
  • Series : Banshee Excel Lite
  • Bulb Type : Xenon
  • Housing Colour : White
  • Minimum Decibel : 95dB
  • Maximum Decibel : 110dB
  • Number Of Tones : 32
  • Maximum Temperature : +55°C
  • CODE No.:755-4040
