63-7805-89 Banshee White 32 Tone Electronic Sounder, 9 → 30 V dc, 110dB at 1 Metre 90001R5
model:
63-7805-89
brand:
Hosiden Besson
Product Description
Product Model: 63-7805-89Product Brand: Hosiden Besson […]
Contact Us
Product Details
Product Model: 63-7805-89
Product Brand: Hosiden Besson
Features
- EN54-3 by LPCB. To maintain IP rating when using a deep base, *** wall mounting bracket supplied. Do not drill fixing holes in deep base. Use suitably rated 20mm cable glands to fit cables or conduit via side knock-outs. Fit ‘O ‘ Ring seal between lens and base. Banshee Excel 32 Tone Sounder. The Banshee Excel Sounder from Hosiden Besson has 32 ***r selectable tones with a choice of 3 volume levels. Manufactured from a flame retardant ABS, these sounders are available with a shallow or deep base in either grey, white or red. If a Piezo Horn is not mentioned in the description then the unit will have a Rocking Armature Transducer fitted. Features and Benefits. EN54 - 3 approved by LPCB Ultra low current consumption 32 ***r selectable tones Choice of 3 volume levels Rated IP66 for deep base sounder and IP45 for shallow base sounder Installation via side ; rear cable entry Robust two in two out 2.5mm terminals Easy push ; twist lockable bayonet mounting Temperature range from -40 to +70°C Simple in ; out wiring blocks offering continuous override and dual signalling
Spec
- Quantity:1piece
- Supply Voltage : 9 → 30 V dc
- IP Rating : IP66
- Decibels at 1 Metre : 110dB
- Current Type : DC
- Number Of Tones : 32
- Housing Colour : White
- Mounting Style : Surface Mount
- Diameter : 90 mm
- Minimum Decibel : 95dB
- Maximum Decibel : 110dB
- Series : Banshee
- Maximum Temperature : +70°C
- CODE No.:755-3996
