63-7804-49 Infineon IGW40T120FKSA1 IGBT, 75 A 1200 V, 3-Pin TO-247 IGW40T120FKSA1
Product Description
Product Model: 63-7804-49Product Brand: Infineon Featur […]
Contact Us
Product Details
Product Model: 63-7804-49
Product Brand: Infineon
Features
- Infineon TrenchStop IGBT Transistors, 1100 to 1600V. A range of IGBT Transistors from Infineon with collector-emitter voltage ratings of 1100 to 1600V featuring TrenchStop™ technology. The range includes devices with an integrated high speed, fast recovery anti-parallel diode. Collector-emitter voltage range 1100 to 1600V Very low VCEsat Low turn-off losses Short tail current Low EMI Maximum junction temperature 175°C
Spec
- Quantity:1set(30pieces)
- Maximum Continuous Collector Current : 75 A
- Maximum Collector Emitter Voltage : 1200 V
- Maximum Gate Emitter Voltage : ±20V
- Maximum Power Dissipation : 270 W
- Package Type : TO-247
- Mounting Type : Through Hole
- Pin Count : 3
- Transistor Configuration : Single
- Length : 16.13mm
- Width : 21.1mm
- Height : 5.21mm
- Dimensions : 16.13 x 21.1 x 5.21mm
- Maximum Operating Temperature : +150 °C
- CODE No.:911-4785
