63-7802-97 Si8441AB-D-IS Silicon Labs, PCB SMT, 4-Channel Digital Isolator 1MBps, 2.5 kVrms, 16-Pin SOIC Si8441AB-D-IS
Product Description
Product Model: 63-7802-97Product Brand: Silicon Labs Fe […]
Contact Us
Product Details
Product Model: 63-7802-97
Product Brand: Silicon Labs
Features
- Si84x Series Digital Isolators. The CMOS digital isolators gives the ability to create small size, high performance, lower power, and reliable isolated circuits that compete with optocoupler designs. High Speed High-Efficiency Forward and Reverse Channels High Electromagnetic Immunity
Spec
- Quantity:1bag(2pieces)
- Maximum Data Rate : 1Mbps
- Package Type : SOIC
- Maximum Forward Voltage : 5.5V
- Maximum Input Current : 7.4 mA
- Isolation Voltage : 2.5 kVrms
- Rise Time : 5ns
- Number of Pins : 16
- Mounting Type : Surface Mount
- Minimum Operating Temperature : -40°C
- Maximum Operating Temperature : +125°C
- Length : 10.3mm
- Depth : 2.65mm
- Width : 7.5mm
- CODE No.:753-2251
