Features

• EN 61058. To make a complete illuminated switch you will need the switch, a lens and a filament lamp or LED. For the EAO 31 series of indicators see stock number ; 248-5368 248-5368 typically. For the EAO 31 series of lenses see stock numbers ; 749-2611 749-2611 or ; 248-5425 248-5425 or ; 248-5374 248-5374 typically. For the EAO 31 series tool kit see stock number ; 248-5481 248-5481. For a suitable filament lamp see stock number ; 655-9211 655-9211 typically. For a suitable white single chip LED see stock number ; 225-997 225-997 typically. Illuminated Push Button Switch - EAO 31 Series. The EAO 31 series of illuminated push button switches are suitable for *** in many Human Machine Interface (HMI) panel mounting applications including Process Control, Panel Building, Machinery and Instrumentation. The illuminated push button switches are available in a choice of round (18mm diameter), square (18x18mm) or rectangular (18x24mm) bezels with snap action or low level switching elements with momentary or maintained switching actions. The snap action switching element is a self-cleaning, double-break, snap action system with solder terminals, while the low level switching element is designed for switching low power loads in electronic circuits ranging from 10μA at 100μV up to 100mA at 42Vac/dc, termination is via universal terminals that allow either direct soldering or PCB mounting. Illumination for the EAO 31 series of push button switches is via a T1 midget groove filament lamp or single chip LED with a voltage of between 6 and 48V. For supply voltages above 48V, it is necessary to *** an external series resistor. All EAO 31 series of illuminated push button switches require a 16mm panel cut out and are suitable for panels with a thickness of between 1.5 and 6mm. They have a long life, short rebound time and a stable contact resistance. Various configurations available including low level or snap action elements, momentary or maintained switching actions and normally closed or normally open contacts Raised button profile Self-extinguishing switch and actuator housing material Class II compliant Electric strength 2500Vac 50Hz for 1 minute between all terminals and earth, as per IEC 60512-2-11
