Features

• UL 508, CAN/CSA C22.2 No.14, GL, GOST, CB scheme, CCC, CE ; C-Tick. CT-WBS Series Impulse Timers. The CT-WBS series is a multifunctional electronic timer set from the CT-S range. The series provides up to 10 timing functions and 10 time ranges. All electronic timers from the CT-S range are available with two different terminal versions. You can choose between the proven screw connection technology (double-chamber cage connection terminals) and the completely tool free Easy Connect Technology (push-in terminals). Rated control supply voltage 24 → 48 V dc, 24 → 240 V ac 7 timing functions: Flasher starting with ON, Flasher starting with OFF, Impulse - ON, ON - delay, Fixed impulse with adjustable time delay, Adjustable impulse with fi xed time delay, ON/OFF - function 10 time ranges (0.05 s → 300 h) Precise adjustment by front - face operating elements Screw connection technology or Easy Connect Technology available Enclosure material for highest fire protection classification Tool free mounting and demounting on DIN - rail 2 C/O (SPDT) contacts 22.5 mm (0.89 in) width 2 LEDs for status indication
