Features

• CT-MVS Series Multifunctional Timers. The CT-MVS Series is a set of multifunctional electronic timers from the CT-S range. They provide 5, 10 or 11 timing functions and 10 or 10 (x2) time ranges which are possible between all models within the series. All electronic timers from the CT-S range are available with two different terminal versions. You can choose between the proven screw connection technology (double - chamber cage connection terminals) and the completely tool - free Easy Connect Technology (push-in terminals). This is de****d by either a "P" or "S" at the *** of the manufacturer's part number. Timing functions: ON-delay, OFF-delay with auxiliary voltage, Impulse-ON, Impulse-OFF with auxiliary voltage, Symmetrical ON- and OFF-delay, Flasher starting with ON or OFF, Star-delta change-over with impulse, Pulse former, Accumulative ON-delay, ON/OFF-function 10 time ranges (0.05 s → 300 h) Control input with voltage - related triggering to start timing, to stop/pa*** timing or to select timing function Precise adjustment by front - face operating elements Screw connection technology or Easy Connect Technology available Enclosure material for highest fire protection classification Tool free mounting and demounting on DIN - rail 2 C/O (SPDT) contacts 22.5 mm (0.89 in) width 3 LEDs for status indication
