63-7795-40 Druck ATEX Gauge for Fluid Pressure Sensor, 16bar Max Pressure Reading , 7 → 28 V, G1/4, IP65 X5072-TB-A1-CA-H1-PA 16.0 bar G
Product Description
Product Model: 63-7795-40Product Brand: Druck Features […]
Contact Us
Product Details
Product Model: 63-7795-40
Product Brand: Druck
Features
- UNIK 5000 Series Pressure Sensors. The UNIK 5000 series is a high performance configurable solution to pressure measurement. The pressure sensors *** silicon technology and analogue circuitry which enables high performance for stability, low power and frequency response. Frequency response to 5 kHz High over pressure capability
Spec
- Quantity:1piece
- Pressure Reading Type : Gauge
- Maximum Pressure Reading : 16bar
- Accuracy : ±0.2 %
- Output Type : Analogue
- Media Measured : Fluid
- Process Connection : G1/4
- Analogue Output : 4 → 20 mA
- Response Time : 10 ms
- Maximum Current : 20 mA
- Supply Voltage : 7 → 28 V
- Housing Material : Stainless Steel
- IP Rating : IP65
- Hazardous Area Certification : ATEX
- CODE No.:746-3477
