Electronic/Electrical Parts and Controll Equipments
63-7789-81 Schneider Electric 3 Pole Contactor, 38 A, 24 V dc Coil, TeSys D, 3NO LC1D38BLS177
model:
63-7789-81
brand:
Schneider Electric
Product Description
Product Model: 63-7789-81Product Brand: Schneider Elect […]
Contact Us
Product Details
Product Model: 63-7789-81
Product Brand: Schneider Electric
Features
- UL and CSA. Contactors suffixed BL accept front mount auxiliary contact blocks but only the 2 contact version, they do not accept side mounted contacts. 3 Pole Contactors, DC Controlled. Built-in coil suppression 3 N/O poles Auxiliary contact configuration one N/O, one N/C Operating time closing 12 to 22 ms Operating time opening 4 to 19 ms
Spec
- Quantity:1piece
- Coil Voltage : 24 V dc
- Number of Poles : 3
- Contact Current Rating : 38 A
- Range : TeSys D
- Series : LC1D
- Normal State Configuration : 3NO
- Auxiliary Contact Configuration : 1NO/1NC
- Contact Voltage Rating : 690 V ac/dc
- Number Of Auxiliary Contacts : 2
- Terminal Type : Screw
- Width : 45mm
- CODE No.:743-5305
