63-7789-63 Bourns SRN3015 Series Type 3015 Shielded Wire-wound SMD Inductor with a Ferrite Core, 1.5 μH ±30% Wire-Wound 2.1A Idc SRN3015-1R5Y
Product Description
Product Model: 63-7789-63Product Brand: Bourns Features […]
Contact Us
Product Details
Product Model: 63-7789-63
Product Brand: Bourns
Features
- AEC-Q200. SRN3015 Series Semi Magnetically Shielded Wire Wound Chokes. Bourns SRN3015 series miniature SMD semi-shielded power inductors feature an inductance range of 1 to 47uH and a rated current up to 2.2A, operating temperature of -40°C to +125°C. These inductors are suitable for the automotive industry and are AEC-Q200 qualified. Applications. Automotive systems: Driver assistant, information, lighting, entertainment DC-DC convertors Power supplies Televisions Digital video
Spec
- Quantity:1bag(10pieces)
- Inductance : 1.5 μH
- Maximum DC Current : 2.1A
- Package/Case : 3015
- Length : 3mm
- Depth : 3mm
- Height : 1.5mm
- Dimensions : 3 x 3 x 1.5mm
- Shielded : Yes
- Tolerance : ±30%
- Maximum DC Resistance : 66mΩ
- Series : SRN3015
- Core Material : Ferrite
- Maximum Self Resonant Frequency : 130MHz
- Inductor Construction : Wire-Wound
- CODE No.:743-5052
