63-7786-25 SPDT Roller Lever Microswitch, 10 A @ 250 V ac 1006.1201
Product Description
Product Model: 63-7786-25Product Brand: Marquardt Featu […]
Contact Us
Product Details
Product Model: 63-7786-25
Product Brand: Marquardt
Features
- UL; CSA; ENEC. The current rating and life expectancy figures quoted are nominal, please see datasheet for further ratings. Marquardt Miniature Snap Action Switches - 1005 Series. Marquardt 1005 Series miniature snap action single pole switches. The 1005 Series snap action switches are designed to DIN41635A with a contact resistance of ;100mΩ and an insulation resistance of >100MΩ. The Marquardt 1005 Series is available with various actuators and terminations. Contact distance ;3mm (apart from stock number ; 741-0978 741-0978 which has a contact distance greater than 3mm) Bounce time ;10ms UL 94 V-2 flammability
Spec
- Quantity:1piece
- Actuator Type : Roller Lever
- Terminal Type : Tab
- Contact Current Rating : 10 A @ 250 V ac
- Contact Configuration : SPDT
- Operating Force : 1.5 → 2.5 N
- Minimum Operating Temperature : -40°C
- Maximum Operating Temperature : +100°C
- Switch Housing : V0 Housing
- Contact Material : Silver
- Case Material : Thermosetting Plastic
- Mechanical Life : 5000000Cycles
- Operating Temperature Range : -40 → +100°C
- CODE No.:741-0965
