63-7782-84 ifm electronic Photoelectric Sensor Diff*** 15 → 400 mm Detection Range PNP OJ5044
model:
63-7782-84
brand:
ifm electronic
Product Description
Product Model: 63-7782-84Product Brand: ifm electronic […]
Contact Us
Product Details
Product Model: 63-7782-84
Product Brand: ifm electronic
Features
- CE, UL. Basic clip, E20964, 2 mounting screws, M3 x 16, 2 spring washers, 2 nuts. OJ Series - Photoelectric Sensors. Efector 200 range of Photoelectric Sensors. Diff*** reflection, rectangular, plastic sensor with quick disconnect Electrical design: DC PNP Output: Light on / Dark on programmable Current Rating: 200 mA Switching status LED (yellow) Power LED (green) Non latching short circuit protection Overload and reverse polarity protection IP rating: IP67 Electronic lock External teach function
Spec
- Quantity:1piece
- Sensor Style : Block
- Detection Type : Diff***
- Detection Range : 15 → 400 mm
- Output Type : PNP
- Electrical Connection : 4-Pin M8 Connector
- Maximum DC Voltage : 30V
- Light Source : LED
- IP Rating : IP67
- Maximum Current : 200 mA
- Housing Material : ABS
- Maximum Operating Temperature : +60°C
- CODE No.:739-6660
