63-7781-86 Key Switch, SPDT, 1 A @ 24 V dc 2-Way, -20 → +65°C HRL-5-E-S-2-RS
Product Description
Product Model: 63-7781-86Product Brand: Lorlin Features […]
Contact Us
Product Details
Product Model: 63-7781-86
Product Brand: Lorlin
Features
- 16mm High Retention Key Switch - HRL Series. Single or double pole, two position, high retention, miniature HRL Key Switch from Lorlin Electronics. The 5 disk HRL Key Switch is available with a tapered bezel and a same (common) key profile. The HRL Key Switch features a high retention module ideal for portable and vehicle applications. 16mm panel cut out Zinc alloy housing with a tapered bezel Trapped key removal (key removable in 12 o'clock position) Supplied with 2 nickel plated mild steel keys Double entry keys (can be inserted into the lock either way up) Single pole versions have 90° total movement and indexing Double pole versions have 60° total movement and indexing
Spec
- Quantity:1piece
- Number of Positions : 2
- Contact Configuration : SPDT
- Key Trapping : Yes
- Contact Current Rating : 1 A @ 24 V dc
- Key Type : Common
- Terminal Type : Solder
- Case Material : Glass Fibre Reinforced PA
- Bezel Shape : Tapered
- Depth Behind Panel : 29.6mm
- Key Index Angle : 90°
- Contact Material : Silver Plated Brass
- Operating Temperature Range : -20 → +65°C
- CODE No.:739-2918
