63-7776-46 Sensata / Crydom 50 A SPST Solid State Relay, Instantaneous, Panel Mount, SCR, 530 V rms Maximum Load HD4850-10
model:
63-7776-46
brand:
Sensata / Crydom
Product Description
Product Model: 63-7776-46Product Brand: Sensata / Crydo […]
Contact Us
Product Details
Product Model: 63-7776-46
Product Brand: Sensata / Crydom
Features
- UL recognised component for Canada and US, VDE. Derating will limit the maximum load current at temperatures above 25 °C. Heat sink not included. For load current de-rating and heat sink details see manufacturers datasheet. Series HD/HA Solid State Relay ac O/P. 1200V blocking capacity SCR Output Low input current requirements, dc versions: 2mA, ac versions: 4mA Terminal Type Screw; Saddle Clamp Input-output Capacitance: 8pF Isolation Voltage 4kVrms Dimensions: H22.9 x D58.4 x W45.7mm
Spec
- Quantity:1piece
- Minimum Load Current : 40 mA rms
- Maximum Load Current : 50 A
- Mounting Type : Panel Mount
- Minimum Load Voltage : 48 V rms
- Maximum Load Voltage : 530 V rms
- Minimum Control Voltage : 3 V dc
- Maximum Control Voltage : 32 V dc
- Switching Type : Instantaneous
- Contact Configuration : SPST
- Terminal Type : Screw
- Output Device : SCR
- Maximum Turn On Time : 1/2 cycle
- Dimensions : 45.7 x 19.8 x 58.4mm
- Length : 45.7mm
- CODE No.:736-0918
