63-7772-66 TRACOPOWER TRA 1 1W Isolated DC-DC Converter Through Hole, Voltage in 4.5 → 5.5 V dc, Voltage out ±12V dc TRA 1-0522
Product Description
Product Model: 63-7772-66Product Brand: TRACOPOWER Feat […]
Contact Us
Product Details
Product Model: 63-7772-66
Product Brand: TRACOPOWER
Features
- IEC 60950-1, EN 60950-1. MTBF to MIL-HDBK-217F (25°C). 3. Traco 1W SIP Single/Dual Output Semi-regulated Isolated DC-DC Converter - TRA 1 Series. 1W single/dual output semi-regulated DC/DC converters with a miniature design and input/output isolation. These semi-regulated DC/DC converters are ideal for *** within power drivers and circuits where unregulated DC/DC converters do not meet the input voltage range at load change. Miniature design with industry standard pinout Semi-regulated output (load) Input / output isolation voltage of 1000 Vdc High efficiency of up to 88%
Spec
- Quantity:1piece
- Output Voltage : ±12V dc
- Input Voltage Range : 4.5 → 5.5 V dc
- Input Voltage Nominal : 5 V dc
- Isolation Voltage : 1000V dc
- Power Rating : 1W
- Output Current : ±42mA
- Mounting Type : Through Hole
- Number of Outputs : 2
- Efficiency : 86%
- Package : SIP
- Load Regulation : ±4.6%
- Maximum Temperature : +85°C
- Length : 19.5mm
- CODE No.:733-1516
