63-7768-92 RS PRO Photoelectric Sensor Retroreflective 7.2 m Detection Range PNP 729-5205
Product Description
Product Model: 63-7768-92Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-7768-92
Product Brand: RS PRO
Features
- bracket. Miniature Block Style (31.5x21mm) Photoelectric Sensors. An economy range of miniature photoelectric sensors offering a choice of diff*** (direct detect), retro-reflective and thru-beam detection methods.,Ho***d in IP67 protected ABS/Polycarbonate bodies with CE certification these compact sensors are ideal for sensing applications where space is limited. Cost effective alternative to leading brand miniature sensors Standard 25.4mm mounting hole spacing (bracket supplied) Diff*** sensing versions offer adjustable sensitivity Dual LED status indication Easy alignment with visible light spot Retro-reflective sensors are supplied complete with reflector
Spec
- Quantity:1piece
- Sensor Style : Block
- Detection Type : Retroreflective
- Detection Range : 7.2 m
- Output Type : PNP
- Electrical Connection : 3-Wire Cable 2m
- Maximum DC Voltage : 24V
- Light Source : LED
- IP Rating : IP67
- Maximum Current : 100 mA
- Response Time : <625 μs
- Housing Material : ABS, PC
- Mounting Type : Flange Mount
- CODE No.:729-5205
