Electronic/Electrical Parts and Controll Equipments
63-7766-33 BT139-600E,127 16A, 600V, TRIAC, Gate Trigger 1.5V 25mA, 3-pin, Through Hole, TO-220AB WeEn Semiconductors Co., Ltd BT139-600E,127
model:
63-7766-33
brand:
WeEn Semiconductors Co., Ltd
Product Description
Product Model: 63-7766-33Product Brand: WeEn Semiconduc […]
Contact Us
Product Details
Product Model: 63-7766-33
Product Brand: WeEn Semiconductors Co., Ltd
Features
- TRIAC, WeEn Semiconductors
Spec
- Quantity:1bag(5pieces)
- Rated Average On-State Current : 16A
- Mounting Type : Through Hole
- Package Type : TO-220AB
- Maximum Gate Trigger Current : 25mA
- Repetitive Peak Reverse Voltage : 600V
- Surge Current Rating : 170A
- Pin Count : 3
- Maximum Gate Trigger Voltage : 1.5V
- Repetitive Peak Forward Blocking Voltage : 600V
- Maximum Holding Current : 45mA
- Dimensions : 10.3 x 4.7 x 9.4mm
- Length : 10.3mm
- Width : 4.7mm
- Height : 9.4mm
- Maximum Operating Temperature : +125 °C
- CODE No.:727-1139
