Electronic/Electrical Parts and Controll Equipments
63-7764-44 Crouzet 6 Digit, LCD, Digital Counter, 40kHz, 30 V dc 87621111
Product Description
Product Model: 63-7764-44Product Brand: Crouzet Feature […]
Contact Us
Product Details
Product Model: 63-7764-44
Product Brand: Crouzet
Features
- UL, CE. Single/Dual Preset Multifunction LCD Counters - CTR48. Counter, tachometer, chronometer, multi-totaliser, batch counter, preselection totaliser Maximum input frequency 40 KHz Simple parameter setting, configuration using text menus Easy modification of presets Scaling factor 5 A changeover relay and solid state output Removable connectors Backlit LCD display (orange): 2 lines, 6 digits or multicoloured display (green-red) IP65 sealed panel protection Option of locking the keypad, completely or partially (preset, programming) Accessories include 72 x 72, 55 x 55 cut-out or a DIN rail adaptor
Spec
- Quantity:1piece
- Supply Voltage : 30 V dc
- Count Mode : Hours
- Display Type : LCD
- Input Type : Voltage
- Connection Type : Screw
- Reset Method : Manual, Signal
- Number of Digits : 6
- Mounting Type : Panel Mount
- Output / Interface : Relay
- Count Direction : Directional, Phase, Up
- Digit Height : 9 mm
- Backlighting : Yes
- Maximum Count Frequency : 40kHz
- Display Range : -999999 → 999999
- Measurement Range : -999999 → 999999
- CODE No.:725-9372
