Features

• UL/cUL 60950-1, CSA-C22.2 No.60950-1, IEC/EN 60950-1, 2nd Edition. UL. MTBF to MIL-HDBK-217 For information on temperature derating please see datasheet on website. Murata 66W to 75W Single Output Regulated Isolated DC-DC Converter - UWE Series. 66W to 75W isolated DC to DC converters with single output and compact eighth brick package that can be plugged directly into quarter brick pinouts. The high efficiency of these 66W to 75W isolated DC to DC converters reduces heat buildup, enabling "no fan" operation. These 66W to 75W isolated DC to DC converters have low on-resistance FETs, planar magnetics and heavy copper PC boards and deliver low output noise, tight line/load regulation, stable no load operation and fast load step response. Suitable applications for these DC to DC converters include battery powered, telecom or portable applications. Industry standard eighth brick package with 0.9" x 2.3" x 0.38" outline Wide 4:1 input power range Synchronous rectification enabes high efficiency and low power dissipation Low output noise Stable no-load operation Extensive self protection, overtemperature and overload features with no output reverse conduction On/Off control, trim and remote sense functions Pre-bias operation for startup protection Meets EN55022 and CISPR22 class B with external filter
