Electronic/Electrical Parts and Controll Equipments
63-7763-27 Murata LQH32CN Series Type 1210 (3225M) Wire-wound SMD Inductor 150 nH ±20% Wire-Wound 1.45A Idc LQH32CNR15M33L
Product Description
Product Model: 63-7763-27Product Brand: Murata Features […]
Contact Us
Product Details
Product Model: 63-7763-27
Product Brand: Murata
Features
- Murata 1210 LQH32CN Series Wire Wound Inductor. Coil inductors with ferrite core. High quality and low DC resistance. Low voltage drop and high temperature stability. Applications: Filtration inductor for switch mode power supplies.
Spec
- Quantity:1bag(10pieces)
- Inductance : 150 nH
- Maximum DC Current : 1.45A
- Package/Case : 1210 (3225M)
- Length : 3.2mm
- Depth : 2.5mm
- Height : 2mm
- Dimensions : 3.2 x 2.5 x 2mm
- Tolerance : ±20%
- Maximum DC Resistance : 28mΩ
- Series : LQH32CN
- Maximum Self Resonant Frequency : 400MHz
- Minimum Operating Temperature : -40°C
- CODE No.:725-5033
