Spec

• Key Features
• Compatible with 2x peak load, ideal for drivetrain load, more than 5% higher efficiency at full load than conventional products, contributing to energy saving in equipment
• It is significantly smaller and lighter by more than 30% compared to conventional models. Volume ratio: 33% reduction, weight ratio: 31% reduction
• Significantly reduced standby power when control is off (R option model)
• Operating ambient temperature of 50 deg. C and use of 100% load factor (standard installation)
• Key Specifications
• Output Power 151.2 W
• Input voltage range 85 ~ 265 VAC (47 ~ 63 Hz) or 120 ~ 370 VDC
• Output voltage DC 24 V
• Output Current 6.3 A
• Efficiency (typ) 0.87/0.90 (100/200 VAC)
• Operating temperature range Natural normal time: -10 to + 70 degrees C (-10 to + 50 C: 100%, + 60 C: 75%, + 70 C: 50%)
• Dimensions 75 x 37 x 160 mm
• Remarks No cover
• RoHS compliant
