62-0564-74 ［Discontinued］Twisted Pair Multi Pair Cable (SPMC) (64 Cores) 1m SPMC-64DG
Product Description
Product Model: 62-0564-74Product Brand: FA Ubon Feature […]
Contact Us
Product Details
Product Model: 62-0564-74
Product Brand: FA Ubon
Features
- Since it is a twisted pair (anti-twist), it has good noise resistance and crosstalk characteristics, making it ideal for wiring high-speed signal circuits.
- The conductor ***s 30/0.08 unique thin wire, so it is soft and has excellent b***ing resistance.
- The ring mark makes it easy to identify up to 100 colors of the core wire, so there is no need to worry about miswiring.
- Shield leader wire (12/0. 12 tin plating) is included for easy shielding.
Spec
- Cut length: 1m
- Format: SPMC-64DG
- Conductor configuration: 30/0.08
- Conductor size: 26AWG
- Conductor outer diameter: 0.51mm
- PVC coat outside: 13.8mm
- PVC outline outer diameter: 1.1mm
- Shield braid pitch: 40mm
- Shield braid outer diameter: 11.2mm
- Number of cores: 64
- Logarithm: 32
- Shield braid configuration: Tin plating 9/0.12/24
- Leader configuration: Tin plating 12/0.12
- Insulator material: PVC
- Rating voltage: 300V、 Rating temperature: 60℃
