63-7730-70 Schaffner FN 3280 Series 64A 520 V ac 60Hz Flange Mount RFI Filter, with Screw Terminals FN3280H-64-34
Product Description
Product Model: 63-7730-70Product Brand: Schaffner Featu […]
Contact Us
Product Details
Product Model: 63-7730-70
Product Brand: Schaffner
Features
- FN 3280 Series. FN3280 series compact and lightweight 3 phase + neutral line filters Design optimised for industrial equipment combining exceptional attenuation with low leakage current Suitable for machines in mixed domestic environments (Class A/B) Operated directly on the mains input the immunity is increased Solid touch safe terminal blocks offering a contacting cross section according to EN 60204-1 Simple and time saving installation with good accessibility for automatic and hand tools The filter current ratings are aligned with common f*** values for ease of selection
Spec
- Quantity:1piece
- Maximum Current Rating : 64A
- Maximum Voltage Rating : 520 V ac
- Mounting Type : Flange Mount
- Termination Style : Screw
- Series : FN 3280
- Operating Frequency : 60Hz
- Length : 153mm
- Depth : 238mm
- Height : 125mm
- Dimensions : 153 x 238 x 125mm
- Leakage Current : 1 mA
- Maximum Operating Temperature : +100°C
- Power Loss : 18.4W
- CODE No.:708-4339
