Features

• UL 60950-1, IEC 60950-1, EN 60950-1. MTBF to MIL-HDBK-217F (25°C) ,Derate above 60°C For suitable common mode chokes: TEP 75-24xx : see stock number ; 745-1228 745-1228 (L1) and (L2) TEP 75-48xx : see stock number ; 745-1212 745-1212 (L1) and stock number ; 745-1225 745-1225 (L2). 3. Traco 75W Single Output Regulated Isolated DC-DC Converter - TEP-75WI Series. 75W single output regulated isolated high performance PCB mount dc-dc converter modules in a rugged, sealed metal case with four threaded M3 inserts for attachment of a heatsink (see ; 706-6420 706-6420 for suitable heatsink). These single output regulated isolated high performance dc-dc converters have a high efficiency allowing an operating temperature up to +60°C with natural convection cooling without power derating, output voltage trimming and remote On/Off. Ultra wide 4:1 input voltage range Soft start Full load operation up to 60°C with convection cooling Remote On/Off Output current limitation Under voltage lockout Reverse input voltage protection Over temperature, over voltage and short circuit protection
