Features

• Spacial SM Monobloc Enclosures. The Spacial SM compact metal enclosure is made up of a compact body, welded rear panel and front part forming a rigid frame with its corners welded. Four deep supports, 2 at the top and 2 at the bottom, for adjusting the equipment fixing bracket with a pitch of 25 mm Sheet steel door, painted with epoxy polyester resin in textured RAL7035 grey Reinforcement frame made up of two perforated uprights with a pitch of 25mm and two door rails (height-adjustable), which can be ***d for fixing cables Standard locking system with handle and 5mm double bar insert Supplied with galvanised mounting plate and 4 support brackets Cable gland plate in 2 parts IP55 according to IEC 60529 IK10 according to IEC62262 Certifications: BV, DNV, UL and cUL
