63-7723-10 Recom R2D 2W Isolated DC-DC Converter Surface Mount, Voltage in 4.5 → 5.5 V dc, Voltage out ±15V dc R2D-0515
Product Description
Product Model: 63-7723-10Product Brand: Recom Features […]
Contact Us
Product Details
Product Model: 63-7723-10
Product Brand: Recom
Features
- UL60950-1, EN-60950-1. CB, CSA, UL recognised component. Operating temperature is without derating. MTBF to MIL-HDBK 217F (+25°C). Recom 2W SMD Single/Dual Output Unregulated Isolated DC-DC Converter - R2S ; R2D Series. Enclosed un-potted open frame type converters Full power at 100°C ambient temperature 1kVdc isolation voltage Short circuit protection High efficiency up to 85%
Spec
- Quantity:1piece
- Output Voltage : ±15V dc
- Input Voltage Range : 4.5 → 5.5 V dc
- Input Voltage Nominal : 5 V dc
- Isolation Voltage : 1kV
- Power Rating : 2W
- Output Current : ±66mA
- Mounting Type : Surface Mount
- Number of Outputs : 2
- Package : SMD
- Load Regulation : ±10%
- Maximum Temperature : +100°C
- Depth : 8.7mm
- CODE No.:706-3727
