63-7721-29 Siemens 3 Pole Contactor, 9 A, 110 V ac Coil, SIRIUS Innovation, 3NO, 4 kW 3RT2016-1AF01
Electronic/Electrical Parts and Controll Equipments

63-7721-29 Siemens 3 Pole Contactor, 9 A, 110 V ac Coil, SIRIUS Innovation, 3NO, 4 kW 3RT2016-1AF01

model: 63-7721-29
brand: Siemens

Product Description

Product Model: 63-7721-29Product Brand: Siemens Feature […]

Contact Us

Hotline

18866622123

WeChat

WeChat ID: 18866622123

WeChat QR Code

Product Details

Product Model: 63-7721-29
Product Brand: Siemens

Features

  • CE, UL, CSA, CCC. Screw terminals can only be ***d with screw terminal overloads and spring terminals can only be ***d with spring terminal overloads. Contactors – 3RT2 Range. The 3RT2 contactors are climate-proof and are suitable and tested for *** worldwide, sizes S00 to S2, up to 37 kW. Size S00, up to 7.5 kW Size S0, up to 18.5 kW Size S2, up to 37 kW Screw connection / Spring Clamp Impulse voltage resistance 6 kV Insulation voltage 690 V Real loss power only 4 W Designation K according to DIN 40719 (ext***able to IEC 204-2) ; IEC 750; Q according to DIN EN 61346-2

Spec

  • Quantity:1piece
  • Coil Voltage : 110 V ac
  • Number of Poles : 3
  • Contact Current Rating : 9 A
  • Power Rating : 4 kW
  • Range : SIRIUS Innovation
  • Series : 3RT2
  • Normal State Configuration : 3NO
  • Contact Voltage Rating : 400 V ac
  • Number Of Auxiliary Contacts : 1
  • Terminal Type : Screw
  • Length : 57.5mm
  • CODE No.:706-1112
