Electronic/Electrical Parts and Controll Equipments
63-7714-46 ITW Single Pole Single Throw (SPST) Latching Red LED Push Button Switch, IP67, 1.29 (Dia.)mm, PCB 48-6-RB-R-GR-B
Product Description
Product Model: 63-7714-46Product Brand: ITW Features 48 […]
Contact Us
Product Details
Product Model: 63-7714-46
Product Brand: ITW
Features
- 48 Series IP67 Sealed. Rugged sealed pushbutton switches with various options of termination type and LED illumination. Long-life (100,000 ops) gold-plated SPNO contacts Rating 250mA @ 12Vdc, 100mA 48Vdc IP67 panel sealing 17.4mm diameter, 13.6mm panel mounting cut-out Suitable for panel thickness of 0.5 to 3.0mm
Spec
- Quantity:1piece
- Switch Operation : Latching
- Mounting Type : PCB
- Illuminated : Yes
- Contact Configuration : Single Pole Single Throw (SPST)
- Panel Cut Out Size : 1.29 (Dia.)mm
- Panel Cut Out Diameter : 1.29mm
- LED Colour : Red
- IP Rating : IP67
- Actuator Colour : Green
- Contact Current Rating : 250 mA @ 12 V dc
- Actuator Shape : Round
- Terminal Type : Through Hole
- Actuator Type : Button
- CODE No.:702-7046
