63-7714-43 ITW Single Pole Single Throw (SPST) Momentary Push Button Switch, IP67, 12.9 (Dia.)mm, PCB 48-5-RB-N-BK-B
Product Description
Product Model: 63-7714-43Product Brand: ITW Features 48 […]
Contact Us
Product Details
Product Model: 63-7714-43
Product Brand: ITW
Features
- 48 Series IP67 Sealed. Rugged sealed pushbutton switches with various options of termination type and LED illumination. Long-life (100,000 ops) gold-plated SPNO contacts Rating 250mA @ 12Vdc, 100mA 48Vdc IP67 panel sealing 17.4mm diameter, 13.6mm panel mounting cut-out Suitable for panel thickness of 0.5 to 3.0mm
Spec
- Quantity:1box(50pieces)
- Switch Operation : Momentary
- Mounting Type : PCB
- Illuminated : No
- Contact Configuration : Single Pole Single Throw (SPST)
- Panel Cut Out Size : 12.9 (Dia.)mm
- Panel Cut Out Diameter : 12.9mm
- IP Rating : IP67
- Actuator Colour : Black
- Contact Current Rating : 250 mA @ 12 V dc
- Actuator Shape : Round
- Terminal Type : Through Hole
- Case Colour : Black
- CODE No.:173-8558
