Features

• UL 94V-0. IC Pin Connectors. Brought to you by Preci-Dip, the 800 Series of IC Pin Connectors are available as either solder tail through Hole 90° headers or straight SMD PCB headers. Each version has an 0.74mm diameter pin with a 2.54 mm pitch, and have brass, tin plated terminations. The Through Hole 90° headers have a tail length of 3.2 mm. The 800 Series of IC Pin Connectors are insulated with glass-filled polyester and have an operating temperature range of -55°C to +125°C. The connectors are available in 2 to 24 contact versions. The 80*-80-***- 30-001 *** SMD mounting headers are Gull-Wing type The 80*-80-***- 30-480 *** SMD mounting headers are Pad type
