63-7712-93 RS PRO Inductive Sensor 5 mm Detection, M18 x 1, PNP-NO, 48mm Length, 10 → 30 V dc supply voltage 701-8213
Product Description
Product Model: 63-7712-93Product Brand: RS PRO Features […]
Contact Us
Product Details
Product Model: 63-7712-93
Product Brand: RS PRO
Features
- Ext***ed Range. RS Pro inductive sensors offer precise detection, long-term reliability and high accuracy. The sensors are completely encapsulated, which greatly increases shock and vibration resistance. Features and Benefits. IP67 Nickel brass housing with PBT sensing face Non embeddable LED indication Operating temperature range -25 to +75°C Short circuit, overload and reverse polarity protection 2m PVC Pre-wired EN60947-5-2 Non-flush mounting
Spec
- Quantity:1piece
- Body Style : Barrel
- Thread Size : M18 x 1
- Output Type : PNP-NO
- Detection Range : 5 mm
- Terminal Type : Cable
- Supply Voltage : 10 → 30 V dc
- Length : 48mm
- Maximum DC Voltage : 30V
- Mounting Type : Flush Mount
- Switching Current : 200 mA
- Housing Material : Nickel Plated Brass
- Minimum Operating Temperature : -25°C
- CODE No.:701-8213
